In modern electronic designs, SMD multilayer solid capacitors play a crucial role in achieving stable performance within limited PCB space. Suntan’s TS13MA and TS13MB series are designed for applications that require low ESR, long operating life, and consistent electrical characteristics across a wide temperature range.
Key Features
◍ Long lifespan – 2,000 hours endurance at 105 °C for reliable operation
◍ Low ESR (Equivalent Series Resistance) – Supports high-frequency and low-impedance designs
◍ Operating temperature range – -55 °C to +105 °C
◍ Voltage range – 2 V to 25 V DC
◍ RoHS compliant and lead-free – Environmentally responsible choice
◍ Compact SMD case size – 7.3 × 4.3 mm footprint for space-saving PCB layouts
| Model | Height | Capacitance | Min. ESR | Max. Ripple Current | Applications |
|---|---|---|---|---|---|
| TS13MA – Ultra-Low Profile | 1.9 mm – slim & space-saving | 2.2 µF – 470 µF | 4.5 mΩ @ 100 kHz | N/A | Portable electronics, displays, thin equipment |
| TS13MB – Higher Capacity | 2.8 mm – higher capacity | 6.8 µF – 680 µF | N/A | 4,800 mArms @ 100 kHz | Power filtering, VRM, graphic cards, chargers |
Common Application Areas
System boards and motherboards – Stable power delivery for processors
Graphics and display cards – Low ESR supports high-speed processing
Power modules and VRMs – Improved voltage regulation under load changes
Consumer electronics – Smart TVs, adapters, and portable chargers
Why They Are Reliable and Compact
Both series combine solid electrolyte technology with multilayer SMD construction, resulting in improved circuit stability, reduced ripple noise, and extended component lifespan. The compact footprint enables high-density PCB layouts without compromising performance.
🎥 Watch how the TS13MA / TS13MB SMD Multilayer Solid Capacitors deliver stable performance in compact power designs.
This short video demonstrates key features, applications, and why these capacitors are trusted in space-constrained, high-performance circuits.
