When it comes to designing reliable and space-efficient electronics, engineers often seek components that can deliver strong electrical performance within a small form factor. Suntan’s TS13C Series SMD Aluminum Electrolytic Capacitors are engineered precisely for this purpose — offering high ripple endurance, low ESR, and dependable stability, even under harsh thermal and frequency conditions.
Compact Design for Dense Layouts
With case sizes as small as Φ4×5.4mm, the TS13C series is ideal for compact designs like LED drivers, DC-DC converters, embedded boards, and industrial modules. Despite the small footprint, these capacitors support ripple currents up to 1190mA (TS13CY model), making them a perfect fit for high-efficiency, thermally demanding environments.
Versatile Sub-Series Tailored for Applications
The TS13C family includes several sub-models designed to meet targeted engineering needs:
• TS13C9: Ultra-low leakage for precision circuitry
• TS13CD: Supports up to 400VDC, ideal for power-intensive systems
• TS13CW: Ensures 10,000 hours of lifetime at 105°C
• TS13CR & TS13CY: High ripple resistance with solvent tolerance
• TS13CJ: Optimized for LED display board performance
This modular range enables engineers to reduce over-specification and achieve precise component matching.
Reliability Under Electrical and Thermal Stress
Designed for high-frequency, high-load conditions, TS13C capacitors maintain performance across wide temperature and frequency ranges. Features include:
• 2,000–10,000 hour lifetime
• Reflow soldering compatibility
• Stable ESR and ripple current tolerance
• RoHS compliance and ripple fatigue resistance
Ideal for telecom filters, automotive control systems, and high-speed digital boards, TS13C offers dependable service life and efficiency.
• TS13C Series Datasheet
• Contact us at: info@suntan.com.hk
Suntan Technology – All Kinds of Capacitors.
We don’t just offer specifications — we deliver confidence for your design and sourcing decisions.
