SMD Rectifier M1-M7 ( SMD 4001-4007 )

SMD Rectifier M1-M7 ( SMD 4001-4007 )SURFACE MOUNT GENERAL RECTIFIER
Reverse Voltage -50 to 1000 Volts Forward Current -1.0 Ampere

SMD Rectifier M1-M7 ( SMD 4001-4007 ) Features

  1. The plastic package carries Underwriters Laboratory Flammability Classification 94V-0
  2. For surface mounted applications
  3. Low reverse leakage
  4. Built-in strain relief, ideal for automated placement
  5. High forward surge current capability
  6. High temperature soldering guaranteed: 250°C/10 seconds at terminals

SMD Rectifier M1-M7 ( SMD 4001-4007 ) MECHANICAL DATA

  1. Case : JEDEC DO-214AC molded plastic body
  2. Terminals : Solder plated solderable per MIL-STD-750, Method 2026
  3. Polarity : Color band denotes cathode end
  4. Mounting Position : Any
  5. Weight : 0.075 grams

SMD Rectifier M1-M7 ( SMD 4001-4007 ) Parameters download PDF files View PDF
