Spark gap capacitors are designed to provide a reliable discharge path for stray, transient overvoltages and static voltage build-up. The construction of the spark gap enable the circuit designer to reduce cost by specifying lower voltage components with the assurance that over-voltage conditions will be prevented.
|Spark Capacitors Specifications|
|Dissipation Factor (DF)||2.5% Max.|
|Insulation Resistance (IR)||7500MΩ Min. or R x C >75Ω·F|
|Encapsulation||Phenolic coated with wax impregnated|
